康明斯高压油泵总成 BP5719
| 参数名 |
参数值 |
| 总成代号 |
BP5719 |
| 配套发动机 |
康明斯 |
| 功率/转速 |
276/2200 |
| 订货号 |
产品标识号 |
柱塞 |
出油阀 |
潍柴发动机型号 |
功率/转速 |
| Ordering code |
P/N |
Plunger |
D/valve |
Weichai Engine Model |
kw/ Rpm |
| 6PW102 |
612601080249 |
U446 |
F167 |
WD615.67G |
154/2200 |
| 6PW102A |
612601080225 |
U446 |
F167 |
WD615.67G |
154/2200 |
| 6PW103 |
|
U456 |
F167 |
WD615.58G |
175/2000 |
| 6PW104 |
|
U456 |
F167 |
WD615.58G |
175/2200 |
| 6PW105 |
|
U456 |
F167 |
WD615.50(公交） |
213km/2200 |
| 6PW106 |
|
U456 |
F167 |
WD615.56(公交） |
198/2200rmp |
| 6PW107 |
|
U456 |
F167 |
WD615.50(车用） |
206/2200 |
| 6PW108 |
|
U456 |
F167 |
WD615.56 |
193/2200 |
| 6PW109 |
|
U456 |
F167 |
WD615.58 |
175/2200 |
| 6PW110 |
|
U446 |
F167 |
WD615.DHG |
118/1800 |
| 6PW111 |
612601080390 |
U446 |
F167 |
WD615.T1-3A |
128/1850 |
| 6PW111A |
612601080439 |
U446 |
F167 |
WD10G175E15 |
128/1850 |
| 6PW112 |
|
U446 |
F167 |
WD615.67G3 |
147/2200 |
| 6PW120 |
612601080375 |
U446 |
F167 |
WD10G210E14 |
154/1900 |
| 6PW121 |
612601080345 |
U446 |
F167 |
WD10G210E12 |
154/2100 |
| 6PW122 |
612601080346 |
U446 |
F167 |
WD10G220E12 |
162/2100 |
| 6PW123 |
612601080383 |
U446 |
F167 |
WD10G220E13 |
162/2100 |
| 6PW124 |
612601080369 |
U446 |
F167 |
WD10G210E11 |
154/2200 |
| 6PW125 |
612601080370 |
U446 |
F167 |
WD10G210E11 |
162/2200 |
| 6PW126 |
612601080347 |
U446 |
F167 |
WD10G240E11 |
175/2200 |
| 6PW127 |
612601080464 |
U446 |
F167 |
WD10G175E13 |
128/2000 |
| 6PW128 |
612601080389 |
U446 |
F167 |
WD10G220E13 |
162/2000 |
| 6PW140 |
612601080607 |
U446 |
F167 |
WD10 |
154/2000 |
| 6PW140A |
612601080578 |
U446 |
F167 |
WD10 |
154/2000 |
| 6PW140C |
|
U446 |
F167 |
WD10 |
154/2000 |
| 6PW141 |
612601080619 |
U446 |
F167 |
WD10 |
162/2000 |
| 6PW142 |
612601080606 |
U446 |
F167 |
WD10 |
154/2200 |
| 6PW142A |
612601080575 |
U446 |
F167 |
WD10 |
154/2200 |
| 6PW142C |
|
U446 |
F167 |
WD10 |
154/2000 |
| 6PW143 |
612601080596 |
U446 |
F167 |
WD10 |
162/2200 |
| 6PW144 |
612601080579 |
U446 |
F167 |
WD10 |
162/2200 |
| 6PW145 |
612601080580 |
U446 |
F167 |
WD10 |
175/2200 |
| 6PW146 |
|
U446 |
F167 |
WD10 |
154/1900 |
| 6PW146A |
612601080581 |
U446 |
F167 |
WD10 |
154/1900 |
| 6PW147 |
612601080576 |
U446 |
F167 |
WD10 |
154/2100 |
| 6PW148 |
6126601080577 |
U446 |
F167 |
WD10 |
162/2100 |
| 6PW149 |
|
U446 |
F167 |
WD10 |
154/1900 |
| 6PW150 |
|
U446 |
F167 |
WD10 |
162/2000 |
| 6PW151 |
|
U446 |
F167 |
WD10 |
162/2100 |
| 6PW152 |
|
U446 |
F167 |
WD10 |
162/2200 |
| 6PW153 |
|
U446 |
F167 |
WD10 |
175/2200 |
| 6PW154 |
612601080591 |
U446 |
F167 |
WD10 |
131/1850 |
| 6PW154A |
612601080583 |
U446 |
F167 |
WD10 |
131/1850 |
| 6PW155 |
612601080595 |
U446 |
F167 |
WD10 |
150/2000 |
| 6PW156 |
612601080590 |
U446 |
F167 |
WD10 |
115/1800 |
| 6PW157 |
612601080612 |
U446 |
F167 |
WD10 |
148/1850 |
| 6PW157A |
612601080582 |
U446 |
F167 |
WD10 |
148/1850 |
| 6PW158 |
612601080592 |
U446 |
F167 |
WD10 |
128/2000 |
| 6PW158A |
612601080585 |
U446 |
F167 |
WD10 |
128/2000 |
| 6PW159 |
612601080584 |
U446 |
F167 |
WD10 |
175/2200 |
| 6PW160 |
612601080608 |
U446 |
F167 |
WD10 |
175/2200 |
| 6PW161 |
612601080613 |
U446 |
F167 |
WD10 |
150/2100 |
| 6PW162 |
612601080624 |
U446 |
F167 |
WD10 |
154/2000 |
| 6PW163 |
612601080616 |
U446 |
F167 |
WD10 |
160/2200 |
| 6PW164 |
612601080627 |
U446 |
F167 |
WD10装载机 |
175/2200 |
| 6PW165 |
612601080618 |
U446 |
F167 |
WD10装载机 |
154/2000 |
| 6PW166 |
612601080744 |
U446 |
F167 |
WD10装载机 |
150/2000 |
| 6PW171 |
612601080773 |
U446 |
F167 |
WD10装载机 |
145/1900 |
| 6PW172 |
612601080771 |
U446 |
F167 |
WD10 |
140/2000 |
| 6PW173 |
612601080770 |
U446 |
F167 |
WD10 |
140/2000 |
| 6PW174 |
612601080630 |
U446 |
F167 |
WD10 |
175/2100 |
| 6PW708 |
612000807230 |
U446 |
F153 |
WD615.170C |
125/1800 |
| 6PW709 |
612600087229 |
U446 |
F153 |
WD615.190C |
140/1800 |
| 6PW710 |
|
U446 |
F153 |
WD615.210C |
154/1800 |
| 6P1114 |
612600087166 |
U462 |
F241 |
WD615.67G |
150/2200 |
| 6P1114-2 |
612600087166 |
U462 |
F241 |
WD615.67G3 |
150/2200 |
| 6P1116 |
612600087170 |
U815 |
F238 |
WD615.69(F233) |
247kw/2200rpm |
| 6P1117 |
612600087158 |
U815 |
F238 |
WD615.44(F233) |
235kw/2200rpm |
| 6P1118 |
612601080167 |
U815 |
F238 |
WD615.30(F233) |
221kw/2200rpm |
| 6P1119 |
612601080171 |
U815 |
F238 |
WD615.31(F233) |
228kw/2200rpm |
| 6P1120 |
612601080169 |
U815 |
F238 |
WD615.58(F233) |
175kw/2200rpm |
| 6P1121 |
612600087168 |
U815 |
F238 |
WD615.44 |
243kw/2200rpm |
| 6P1122 |
612600087148 |
U462 |
F241 |
WD615.67G3 |
158kw/2200rpm |
| 6P1122-2 |
612600087148 |
U462 |
F241 |
WD615.67G3 |
158/2200 |
| 6P1129 |
612600087165 |
U815 |
F238 |
WD615.50公交车 |
206/2200 |
| 6P1135 |
612600087202 |
U815 |
F238 |
WD615.30公交车 |
221kw/2200rpm |
| 6P1136 |
612600087191 |
U815 |
F238 |
WD615.44公交车 |
235kw/2200rpm |
| 6P1137 |
612600087200 |
U815 |
F238 |
WD615.50公交（1175NM） |
206kw/2200rpm |
| 6P1138 |
612601080208 |
U815 |
F238 |
WD615.44公交车 |
235kw/2200rpm |
| 6P1139 |
612601080207 |
U815 |
F238 |
WD615.34公交车 |
250kw/2200rpm |
| 6P1139E |
612601080516 |
U815 |
F238 |
WD615.34公交车（出口） |
250kw/2200rpm |
| 6P1140 |
|
U815 |
F238 |
WD615.46公交车 |
265kw/2200rpm |
| 6P1141 |
612601080175 |
U815 |
F238 |
WD615.50公交车 |
213kw/2200rpm |
| 6P1141E |
612601080515 |
U815 |
F238 |
WD615.50（公交）出口机 |
213kw/2200rpm |
| 6P1157 |
612601080176 |
U815 |
F238 |
WD615.56公交车 |
193kw/2200rpm |
| 6P1158 |
612601080152 |
U815 |
F238 |
WD615.58(公交车) |
175kw/2200rpm |
| 6P1159 |
612601080203 |
U815 |
F238 |
WD615.58公交车降扭矩 |
175kw/2200rpm |
| 6P1161 |
612601080108 |
U815 |
F238 |
WD615.58 |
175kw/2200rpm |
| 6P1162 |
612601080219 |
U815 |
F238 |
WD615.44 |
243kw/2200rpm |
| 6P1165 |
612600087214 |
U815 |
F238 |
WD615.X44 |
235kw/2200rpm |
| 6P1166 |
612600087222 |
U815 |
F238 |
WD615.X44 |
235kw/2200rpm |
| 6P1169 |
612600087217 |
U815 |
F238 |
WD615.97 |
273kw/2200rpm |
| 6P1170 |
612601080115 |
U815 |
F238 |
WD615.34 |
250kw/2200rpm |
| 6P1171 |
612601080215 |
U815 |
F238 |
WD615.38A |
280kw/2200rpm |
| 6P1172 |
612600087213 |
U815 |
F238 |
WD615.X46 |
262kw/2200rpm |
| 6P1173 |
612601080216 |
U815 |
F238 |
WD615.46 |
266kw/2200rpm |
| 6P1177 |
612601080116 |
U834 |
F238 |
WD615.38 |
280kw/2400rpm |
| 6P1179 |
|
U815 |
F238 |
WD615.X50 |
206kw/2200rpm |
| 6P1180 |
|
U815 |
F238 |
WD615.X50公交 |
206kw/2200rpm |
| 6P1181 |
612600087245 |
U815 |
F238 |
WD615.X34公交 |
250kw/2200rpm |
| 6P1182 |
612600087246 |
U815 |
F238 |
WD615.X44公交 |
235kw/2200rpm |
| 6P1184 |
612601080233 |
U840 |
F238 |
WD618.420 |
309kw/2200rpm |
| 6P1186 |
612600087234 |
U840 |
F238 |
WD618.420 |
309kw/2200rpm |
| 6P1187 |
612601080226 |
U840 |
F238 |
WD618.390 |
287kw/2200rpm |
| 6P1188 |
612601080232 |
U840 |
F238 |
WD618.375 |
276kw/2200rpm |
| 6P1189 |
612601080231 |
U840 |
F238 |
WD618.336 |
247kw/2200rpm |
| 6P1190 |
612600081227 |
U840 |
F238 |
WD618.420公交 |
309kw/2200rpm |
| 6P1191 |
612600081228 |
U840 |
F238 |
WD618.420公交 |
309kw/2200rpm |
| 6P1192 |
612600087239 |
U840 |
F238 |
WD618.390公交 |
287kw/2200rpm |
| 6P1193 |
612600081235 |
U840 |
F238 |
WD618.375公交 |
276kw/2200rpm |
| 6P1194 |
612600081236 |
U840 |
F238 |
WD618.336公交 |
247kw/2200rpm |
| 6P1196 |
|
U815 |
F241 |
WD615.C |
280kw/2400rpm |
| 6P1199 |
612601080311 |
U840 |
F238 |
WD12.336 |
247kw/1900rpm |
| 6P1200 |
612601080301 |
U840 |
F238 |
WD12.375 |
276kw/1900rpm |
| 6P1201 |
612601080302 |
U815 |
F238 |
WD615.58 |
175kw/1900rpm |
| 6P1202 |
612601080313 |
U815 |
F238 |
WD615.58 |
175kw/1900rpm |
| 6P1203 |
612601080314 |
U815 |
F238 |
WD615.56 |
199kw/1900rpm |
| 6P1204 |
612601080315 |
U815 |
F238 |
WD615.50 |
213kw/1900rpm |
| 6P1205 |
612601080316 |
U815 |
F238 |
WD615.44 |
235kw/1900rpm |
| 6P1210 |
612601080348 |
U815 |
F238 |
WD615.56 |
175kw/2200rpm |
| 6P1218 |
612601080380 |
U840 |
F238 |
WP10.270NE31 |
199kw/2200rpm |
| 6P1219 |
612601080379 |
U840 |
F238 |
WP10.290NE31 |
213kw/2200rpm |
| 6P1220 |
612601080378 |
U840 |
F238 |
WP10.300NE31 |
221kw/2200rpm |
| 6P1221 |
612601080377 |
U840 |
F238 |
WP10.310NE31 |
228kw/2200rpm |
| 6P1222 |
612601080376 |
U840 |
F238 |
WP10.336NE31 |
247kw/2200rpm |
| 6P1223 |
612601080381 |
U840 |
F238 |
WP10.270NE31 |
199kw/1900rpm |
| 6P1224 |
612601080382 |
U840 |
F238 |
WP10.290NE31 |
213kw/1900rpm |
| 6P1225 |
612601080384 |
U840 |
F238 |
WP10.300NE31 |
221kw/1900rpm |
| 6P1226 |
612601080385 |
U840 |
F238 |
WP10.310NE31 |
228kw/1900rpm |
| 6P1227 |
612601080386 |
U840 |
F238 |
WP10.336NE31 |
247kw/1900rpm |
| 6P1228 |
612601080391 |
U840 |
F238 |
WD12.240 |
175kw/1800rpm |
| 6P1229 |
612601080392 |
U840 |
F238 |
WP12 |
185kw/2100rpm |
| 6P1231 |
612601080458 |
U840 |
F238 |
WP10.24NE31 |
175kw/2200rpm |
| 6P1232 |
612601080457 |
U840 |
F238 |
WP10.336NE31 |
266kw/2200rpm |
| 6P1238 |
612601080398 |
U840 |
F238 |
WD12.336E32 |
247kw/2200rpm |
| 6P1239 |
612601080397 |
U840 |
F238 |
WD12.375E32 |
276kw/2200rpm |
| 6P1240 |
612601080396 |
U840 |
F238 |
WD12.420E32 |
309kw/2200rpm |
| 6P1262 |
612601080459 |
U840 |
F238 |
WP10.240NE31 |
175kw/2200rpm |
| 6P1268 |
612601080514 |
U815 |
F238 |
WD615.31 |
225/2200 |
| 6P1269 |
612601080454 |
U840 |
F238 |
WD615.56 |
199/2200 |
| 6P1270 |
612601080453 |
U840 |
F238 |
WD615 |
213/2200 |
